Eight-channel mixed grain sorting machine

Send Inquiry

Request To Call Back

Eight-channel mixed grain sorting machine

Price 28000 INR/ Pair

Get a Price/Quote

MOQ : 1 Pair

Eight-channel mixed grain sorting machine Specification

Shape
Rectangular cabinet design

Phase
Three phase

Product Type
Eight-channel mixed grain sorting machine

General Use
Sorting and grading mixed grain types such as rice, beans, wheat, pulses, seeds, etc.

Material
Stainless steel body and contact parts

Type
Optical grain color sorter

Capacity
5000-8000 kg/h (varies by material type and settings)

Weight (kg)
Approx. 800 kg

Computerized
Yes

Automatic
Yes

Touch Screen
Yes, advanced color touchscreen interface

Control System
Intelligent microcomputer control system

Surface Treatment
Powder coated and polished for corrosion protection

QC System
Integrated automatic QC system

Tolerance
0.01% sorting accuracy

Drawing
Available upon request

Voltage
220V/380V, 50/60Hz (customizable)

Dimension (L*W*H)
2750 x 1500 x 1800 mm

Feature
High precision, low maintenance, multi-channel sorting, self-diagnosis system

Color
Standard white with blue and grey finishes

Air Consumption
0.3-0.6 m3/min at 0.6-0.8 MPa

Cleaning System
Automatic dust cleaning

Channels
8 channels for simultaneous high-volume sorting

Software
Upgradable with cloud integration

Rejection Ratio
<0.5%

Operating Environment
Temperature: 0-40C; Humidity: <90% RH (non-condensing)

Sensor Type
CCD high-resolution sensors with real-time monitoring

Lighting Source
LED solid-state illumination, long lifespan

Installation
Floor mounted, adjustable feet for leveling

Ejector Valve
High-speed air ejector system, long service life

Interface
Ethernet/USB for software updates and data export

Accepted Grain Size Range
0.8 mm - 15 mm

Safety Feature
Emergency stop button, overload protection

Noise Level
75 dB

Power Consumption
3.5 kW

Sorting Accuracy
>99.9%

About Eight-channel mixed grain sorting machine

machinery function: Color Sorter

raw material: Coffee Bean , grains , nuts and so on

Power: 0.5KW

Voltage: 220V/50Hz

Brand name: ZHONGDE

place of origin: He'bei, China

dimension(l*w*h): 1020*500*1520mm

Weight: 150kg

machinery capacity: 0.2-0.4T/H

sorting accuracy: >99.99%

air consumption: 0.1-0.3 (m/Min)

air pressure: 0.6-0.8Mpa

Product name: Color Sorter Machine

Function: Color sorting

After-sales Service Provided: Online Support

Advantage: Intelligent Easy Operation High Efficiency

Operation: Continuous Automatic Sorting

After Warranty Service: 24 Hours Online Support

Packaging and delivery:

Selling Units: Single item / Wooden box

Company Profile:

Xingtai Zhongde Machinery Manufacturing Co., Ltd. is one of the largest manufacturers, exporters, and suppliers of advanced Intelligence Colour Separators. We take pride in our focus on innovation and excellence as it helps us to provide leading edge sorting solutions to a variety of industries, including agricultural, food processing, and recycling industries.

Our separators are extensively praised in the market for improving product quality, optimizing efficiency, and minimizing waste through intelligent color sorting technology. Throughout the years, we have had an excellent reputation in terms of giving high-performance machines that are as per the high global standards.

Xingtai Zhongde boasts itself through offering a flexible solution to our clients in terms of meeting their needs. Our machines are specifically designed to give topmost precision, speed, and durability and because of that reason, we are the company you can rely on globally.

FAQ:

1.Q:How about engineers service oversea?
A:Engineers available to service machinery overseas.

2.Q:How to use the machine?
A:We will supply customer the installation catalog or video online.We will ask our engineer to teach you, how to use when he go to your country to debug the machine.

3.Q:How about the sample machines for testing?
A:Sample sending for testing is welcomed.Or you send these three photos,the raw material,good material (which is you want) ,bad material (which is you want to discard).We send our video to you.

4.Q:How about the guarantee period?
A:One year.

5.Q:Will you accept L/C as payment?
A:L/C ,T/T, Cash, Alipay ect

6.Q:Do you have any other spare parts for the customer?
A:Yes,we will supply you some spare parts.

7.Q:Which machine will work together with our color sorter which you can supply?
A:Air compressor,Air tank,Air filters,Air dryer,Light sources,Cleaning brushes,etc

High-Efficiency Multi-Channel Sorting Technology

With 8 simultaneous sorting channels, this machine delivers exceptional throughput-processing up to 8,000 kg/h, dependent on grain type and settings. Intelligent microcomputer control ensures that every grain is accurately sorted, utilizing advanced CCD sensors and high-speed air ejectors for separation. The result is high sorting precision, minimal wastage, and optimal productivity for commercial grain operations.

User-Friendly Touchscreen and Smart Control

Control and monitor all functions with the intuitive, advanced color touchscreen interface. The system's intelligent microcomputer guarantees seamless processing and allows real-time adjustments. Software is easily updated via Ethernet or USB ports, ensuring compatibility with new features and maintaining peak performance, while cloud integration offers modern data management.

Durable Build with Integrated Safety and Self-Cleaning

Constructed from stainless steel and finished with powder coating, this sorter offers robust corrosion resistance. It operates safely with an emergency stop button and overload protection, while automatic dust-cleaning keeps the system efficient and reduces manual maintenance. Adjustable feet offer easy installation and leveling, making it adaptable for various processing environments.

FAQ's of Eight-channel mixed grain sorting machine:

Q: How does the eight-channel mixed grain sorting machine improve grain sorting efficiency?

A: The machine uses eight synchronized channels and high-resolution CCD sensors to sort large volumes of mixed grains with exceptional precision. This multi-channel design enables it to process up to 8,000 kg of grain per hour, significantly increasing throughput and reducing processing time for grain producers and traders.

Q: What types and sizes of grains can this sorter handle?

A: Designed to be versatile, the machine efficiently sorts a wide variety of grains including rice, beans, wheat, pulses, and seeds. It accommodates grain sizes ranging from 0.8 mm to 15 mm, allowing it to serve diverse sorting needs across different agricultural products.

Q: When should the automatic cleaning function be used, and how does it work?

A: The sorter is equipped with an automatic dust cleaning system that runs periodically to maintain optical clarity and prevent sensor blockages. This feature works continuously during operation, reducing downtime for cleaning and ensuring stable performance with minimal manual intervention.

Q: Where can this sorting machine be installed, and what are its operating requirements?

A: Installation is straightforward as the machine is floor-mounted with adjustable feet for leveling. It operates best in environments with temperatures from 0-40C and humidity below 90% RH (non-condensing). It requires a three-phase power supply (220V/380V, 50/60Hz) and compressed air at 0.6-0.8 MPa.

Q: What benefits does the touch screen interface and cloud-upgradable software provide?

A: The advanced color touchscreen enables intuitive control over all machine functions, allowing for easy adjustments and real-time monitoring. The upgradable software-accessible via Ethernet or USB-ensures the machine stays current with technological improvements and features, and cloud integration allows seamless data management and remote monitoring.

Q: How does the machine ensure safety during operation?

A: Safety is prioritized with features such as an emergency stop button and overload protection. The robust construction and integrated QC system further enhance operational security and guarantee reliable, long-term, and safe use in processing facilities.
